BASIC+ vision camera

---

The Basic+ vision camera is a versatile FullHD Ethernet camera designed for real-time monitoring in demanding environments. Whether installed in mobile machinery, industrial facilities, or stationary systems, it delivers high-resolution imaging to enhance safety, productivity, and process control.

Thanks to its compact and rugged design, the ArkCam Basic+ excels in applications exposed to extreme temperatures, strong vibrations, and wet or dusty conditions. It seamlessly integrates into existing networks and control systems—making it the go-to solution for complex and hazardous operational settings.

Key Features

• FullHD 1920x1080 image sensor for clear, detailed visuals
• Available in Single-Pair Ethernet (100BASE-T1) or Fast Ethernet (100BASE-TX)
• Supports leading protocols: RTP/RTSP, TCP/UDP, REST API, HTTP, ISO17215
• Stream in MJPEG or H.264 video formats
• Optional integrated IR (850nm) or white light LED illumination
• Wide voltage range: 9–60V DC
• Extended temperature range: –40°C to +95°C
• IP69K protection – resistant to high-pressure and steam cleaning
• Vibration resistant up to 50g mechanical load

Built for Real-World Challenges

From freezing temperatures to intense heat, from dusty worksites to high-pressure washdowns—Basic+ vision camera is engineered to perform under pressure. It meets high mechanical and environmental standards, making it the ideal choice for industries like:

• Agricultural machinery
• Construction equipment
• Commercial vehicles and transport systems
• Industrial automation
• Machine vision and process monitoring

Integration Made Simple

With support for popular industry protocols like ONVIF, OPC UA, and REST API, the ArkCam Basic+ integrates smoothly into new or existing system architectures. Overlay capabilities and up to 5 simultaneous video streams allow operators to adapt the camera output to a wide range of use cases.
